Resetting the Sheet Counter

Reset the sheet counters in the following procedure:

  1. Confirm that the scanner is connected to the computer, then turn on the scanner.
  2. Open the [Software Operation Panel] window.
    • Windows Server® 2008/Windows® 7
      Select [Start] menu → [All Programs] → [fi Series] → [Software Operation Panel].
    • Windows Server® 2012
      Right-click the Start screen, and select [All apps] on the app bar → [Software Operation Panel] under [fi Series].>/li>
    • Windows Server® 2012 R2/Windows® 8.1
      Click [↓] on the lower left side of the Start screen and select [Software Operation Panel] under [fi Series].
      To display [↓], move the mouse cursor.
    • Windows® 10/Windows Server® 2016
      Select [Start] menu → [fi Series] → [Software Operation Panel].
  3. From the listing on the left, select [Device Setting].
    reset_roller_counter
  4. After replacing a consumable, click the [Clear] button for the replaced consumable. When you have cleaned the scanner, click the [Clear] button for [After cleaning].
    The counter is reset to "0".
  5. Click the [OK] button on the [Software Operation Panel] window.
    A message window appears.
  6. Click the [OK] button.
    The settings are saved.
