Checking the Sheet Counter
The status on each consumable part can be viewed to determine when to replace or clean the consumables.
When a consumable needs to be replaced or cleaned soon, the background color of the counter for the consumable changes. The background color of counters change at the following times:
- Brake roller/pick roller counters
The background color of the counters turns light yellow when the sheet count reaches 95% of the value that is specified in [Life Counter Alarm Setting] of the Software Operation Panel. The background color of the counters turns yellow when the sheet count reaches 100%. - Sheet counter after cleaning
The background color of the counter turns yellow when the sheet count after cleaning reaches the value that is specified in [Cleaning Cycle] of the Software Operation Panel. - Remaining ink counter
The background color of the counter turns yellow when the amount of remaining ink reaches below 33% (only displayed when the imprinter is installed).
For details about [Life Counter Alarm Setting] and [Cleaning Cycle] of the Software Operation Panel, refer to the Operator's Guide.
The following shows the suggested replacement cycles for consumables when using A4/Letter (80g/m2 (20 lb)) wood-free paper or wood-containing paper. Actual cycles vary depending on the type of documents scanned and how often the scanner is used and cleaned.
| Name | Part No. | Suggested Replacement Cycle |
|---|---|---|
| BRAKE ROLLER | PA03740-K010 | 250,000 sheets or one year |
| PICK ROLLER | PA03740-K011 | 250,000 sheets or one year |
| PRINT CARTRIDGE | CA00050-0262 | 4,000,000 characters or six months after opening |
Check the sheet counters in the following procedure:
- Confirm that the scanner is connected to the computer, then turn on the scanner.
- Open the [Software Operation Panel] window.
- Windows Server® 2008/Windows® 7
Select [Start] menu → [All Programs] → [fi Series] → [Software Operation Panel]. - Windows Server® 2012
Right-click the Start screen, and select [All apps] on the app bar → [Software Operation Panel] under [fi Series]. - Windows Server® 2012 R2/Windows® 8.1
Click [↓] on the lower left side of the Start screen and select [Software Operation Panel] under [fi Series].
To display [↓], move the mouse cursor. - Windows® 10/Windows Server® 2016
Select [Start] menu → [fi Series] → [Software Operation Panel].
- Windows Server® 2008/Windows® 7
- From the listing on the left, select [Device Setting].
